Power over Ethernet (PoE)
Silvertel has designed and developed the widest range of Power over Ethernet (PoE) modules in the world, including the worlds smallest modules, the highest efficiency and the highest power modules available. We manufacture different packages, output power and voltage options to suit a huge variety of applications. Our PoE modules require minimal external components and all have built-in signature recognition complying to the IEEE standards.
Silvertel PoE modules provide a cost effective, easy to use solution for applications in industries such as IoT, IIoT, SMART Industries, Security, AV, Commercial Electronics and more. We offer a full range of Single-In-Line (SIL), Dual-In-Line (DIL) and Surface Mount (SMT) package options.
Click to download our PoE Selector Guide to choose the most suitable solution for you
Isolated Powered Device
Power over Ethernet (PoE): PD up to 13W - IEEE802.3af
Ag9900 Series
The Smallest PoE module solution in the World
• Miniaturised PoE PD module:
SMT Footprint -21mm(L)x14mm(W)x13.35mm(H)
• Ag9900-LPB – Low Profile 8mm Height option also available!
• Smallest PoE solution in the World
• 40% smaller than any other PoE solution
• Overload & Short-Circuit protection
• Over-Temperature and Industrial Temperature protection option
• 1500Vdc Isolation (Input to Output)
• 3V, 5V, 12V & 24V versions
• Isolated DC/DC Converter
• Low cost & Simple integration
Ag9700 Series
Low cost Single-in-Line (SIL) PoE module solution
- Low Cost optimised IEEE802.3af PoE PD Module
- SIL Footprint: 56mm(L)x18mm(W)x14mm(H)
- Industrial temperature option (FL)
- Class programming option
- Overload & short-circuit protection
- Over-temperature protection option
- 3V, 5V, 12V & 24V versions
- Isolated DC/DC converter
- 1500Vdc Isolation (Input to Output)
- Low cost & simple integration
Ag9205
High Efficiency IEEE802.3af PoE module solution
- High efficient DC/DC converter (up to 88% ~ 5V 13W)
- SIL Footprint: 56mm(L)x18mm(W)x14mm(H)
- Very low output ripple and noise
- Overload and short-circuit protection
- Industrial temperature range
- Over-temperature protection
- 1500Vdc Isolation (Input to Output)
- Simple integration
Power over Ethernet (PoE): PD up to 30W - IEEE802.3at
Ag5700-LPB Series
The Smallest IEEE802.3at PoE module solution in the world
• SMT Footprint – 33mm(L)x22mm(W)x13mm(H)
• 89% efficient DC/DC converter
• 12V and 24V variants available
• Overload, short-circuit and thermal protection
• Low output ripple & noise
• Adjustable output voltage
• Industrial temperature range
• Minimal external components required
• Class 4 IEEE802.3 PD
• 1500Vdc Isolation (Input to Output)
Ag5300 Series
The 'original' IEEE802.3at PoE module solution
• SIL Footprint – 57mm(L)x18mm(W)x14mm(H)
• 12V & 24V output options
• Adjustable output voltage
• Input voltage range 37V to 57V
• Overload, thermal and short-circuit protection
• Isolated high efficiency DC/DC converter
• Minimal low cost external components required
• Low cost & simple integration
• 1500Vdc Isolation (Input to Output)
Ag5400 Series
The Highest Efficiency IEEE802.3at Single-in-Line (SIL) PoE module solution in the world
• Very high efficiency (>93%)
• Environmentally friendly – Less Power Loss
• SIL Footprint – 57mm(L)x18mm(W)x14mm(H)
• Very low heat output
• Low output ripple & noise
• Overload, short-circuit and thermal protection
• Adjustable output voltage
• Very few external low cost components required
• Industrial temperature range
• Class 4 IEEE802.3 PD
• 1500Vdc Isolation (Input to Output)
Power over Ethernet (PoE): PD up to 85W - IEEE802.3bt
Power over Ethernet (PoE): PD up to 85W - IEEE802.3bt
Ag59600-LPB Series
The latest IEEE802.3bt High Efficiency (94%) PoE module solution
- 60W peak output power (IEEE802.3bt class 6)
- 51W continuous power
- Small SMT Footprint – 40mm(L)x25mm(W)x16mm(H)
- 94% efficient DC/DC converter
- 12V and 24V variants available
- Excellent thermal management
- Low output ripple & noise
- Overload, short-circuit and thermal protection
- Adjustable output voltage
- Industrial temperature range
- 1500Vdc Isolation (Input to Output)
Ag5800
The Highest Power (85W) IEEE802.3bt PoE module solution
• Dual-in-Line (DIL) Footprint- 70mm(L)x35mm(W)x17mm(H)
• Power received on all 4 pairs – Type 4, Class 8
• Overload, thermal & short-circuit protection
• Very low power standby mode
• Wide input voltage range (37-57V)
• 12V or 24 V output
• 89% efficient isolated DC/DC converter
• Minimal low cost external components required
• 1500Vdc Isolation (Input to Output)
Ag5810
60W IEEE802.3bt High Power PoE module solution
• Dual-in-Line (DIL) Footprint – 70mm(L)x30mm(W)x16mm(H)
• Power received on all 4 pairs – Type 4, Class 7
• Overload, thermal & short-circuit protection
• Very low power standby mode
• Wide input voltage range (37-57V)
• 12V or 24 V output
• 88% efficient isolated DC/DC converter
• Minimal low cost external components required
• 1500Vdc Isolation (Input to Output)
Power Sourcing Equipment
Power over Ethernet (PoE): PSE up to 19W - IEEE802.3af
Ag6130
• Programmable output power limit up to 75W
• Compliant with IEEE802.3af and IEEE802.3at specifications.
• Single power rail feed
• Small SMT Footprint – 21mm(L) x 14mm(W) x 5mm(H)
• Overload, short-circuit and thermal protection
• Minimal (low cost) external components required
• Supports reduced MPS power
• Industrial temperature range
• Simple integration
Ag6120
• Compliant with IEEE802.3af and IEEE802.3at specifications.
• Small SIL Footprint- 53mm(L)x 7mm(W)x 14mm(H)
• Over Current & Short Circuit Protection
• Signature & Class recognition
• Programmable output power limit up to 75W
• IEEE802.3bt reduced MPS for lower power standby
• Very Low Power Dissipation (98% efficient)
• Industrial Temperature range
• Simple integration
Power over Ethernet (PoE): PSE up to 39W - IEEE802.3at
Ag6130
• Programmable output power limit up to 75W
• Compliant with IEEE802.3af and IEEE802.3at specifications.
• Single power rail feed
• Small SMT Footprint – 21mm(L) x 14mm(W) x 5mm(H)
• Overload, short-circuit and thermal protection
• Minimal (low cost) external components required
• Supports reduced MPS power
• Industrial temperature range
• Simple integration
Ag6120
• Compliant with IEEE802.3af and IEEE802.3at specifications.
• Small SIL Footprint-53mm(L)x 7mm(W)x 14mm(H)
• Over Current & Short Circuit Protection
• Signature & Class recognition
• Programmable output power limit up to 75W
• IEEE802.3bt reduced MPS for lower power standby
• Very Low Power Dissipation (98% efficient)
• Industrial Temperature range
• Simple integration
Power over Ethernet (PoE): PSE Ultra 74W
Ag6130
• Programmable output power limit up to 75W
• Compliant with IEEE802.3af and IEEE802.3at specifications
• Single power rail feed
• Small SMT Footprint – 21mm(L)x 14mm(W) x 5mm(H)
• Overload, short-circuit and thermal protection
• Minimal (low cost) external components required
• Supports reduced MPS power
• Industrial temperature range
• Simple integration
Ag6120
• Compliant with IEEE802.3af and IEEE802.3at specifications
• Small SIL Footprint-53mm(L)x 7mm(W)x 14mm(H)
• Over Current & Short Circuit Protection
• Signature & Class recognition
• Programmable output power limit up to 75W
• IEEE802.3bt reduced MPS for lower power standby
• Very Low Power Dissipation (98% efficient)
• Industrial Temperature range
• Simple integration
Power over Ethernet (PoE): PSE up to 99W - IEEE802.3bt
Ag6800
• Cost Optimised 97W PoE PSE Module
• Compliant with IEEE802.3bt specification
• Power out on all 4 pairs
• 57V out for maximum efficiency
• Compact DIL Footprint – 51mm(L) x 35mm(W) x 7mm (H)
• Very high efficiency (99%)
• Overload and short-circuit protection
• IEEE802.3af & 802.3at backward compatible
• Industrial Temperature
• Minimal external components
• Simple integration
